44 Inch OD High Pressure Boiler Tube Alloy Steel ASTM A335 P22 1118mm SCH XXS
A335 P22 (SA-213 T22) is mainly used in steam pipeline, 300 600MW large capacity power plant boiler tube wall temperature are less than 580 of the superheater and the tube wall temperature are less than 540 of the wall and the header, A335 P22 has been widely used in the United States, Japan and Europe, has a long history in power plant operation that is a mature steel stable performance, good process performance.
1. Standards
ASTM A106 ——Standard Specification for Seamless Carbon Steel Pipe for High-Temperature Service
ASTM A335 ——Standard Specification for Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service
2. Application
For the high-pressure boiler and steam pipes, and the petrochemical industry pipes;
Power plant; Chemical Fertilizer; Petrochemicals; Offshore Oils; Gas Productions; Refineries and etc.
3. Steel pipes No. of main production:
ASTM A335 Grade P5, P9, P11, P12, P22, P91, P92
ASTM A106 Grade B, C
4. Dimensional Tolerance
| Pipe types | OD (mm) | Tolerance | WT (mm) | Tolerance |
| High Pressure Boiler Tube | 219~457 | ±1.0％ | ≤20 | -10% ~ +12.5% |
| 20~40 | -10% +10% |
| 457~1422 | ±0.9％ | ＞40~70 | -7％, +9％ |
| ＞70~20 | -6％, +8％ |
5. Chemical Composition:
| High Pressure Boiler Tube Chemical Requirements |
| Standard | Grade | UNS Designation | Composition, % |
| C | Mn | P | S | Si | Cr | Mo | Ni | V | Others |
| ASTM A335 | P5 | K41545 | 0.15max | 0.30-0.60 | 0.025 | 0.025 | 0.50max | 4.00-6.00 | 0.45-0.65 | | | ... |
| P9 | S50400 | 0.15max | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.00-10.00 | 0.90-1.10 | | | ... |
| P11 | K11597 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 | | | ... |
| P12 | K11562 | 0.05-0.15 | 0.30-0.61 | 0.025 | 0.025 | 0.50 max | 0.80-1.25 | 0.44-0.65 | | | ... |
| P22 | K21590 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 max | 1.90-2.60 | 0.87-1.13 | | | ... |
| P91 | K91560 | 0.08-0.12 | 0.30-0.60 | 0.02 | 0.01 | 0.20-0.50 | 8.00-9.50 | 0.85-1.05 | 0.4 | 0.18-0.25 | N 0.030-0.070 |
| Al 0.02max |
| Cb 0.06-0.10 |
| Ti 0.01 max |
| Zr 0.01max |
| P92 | K92460 | 0.07-0.13 | 0.30-0.60 | 0.02 | 0.01 | 0.50 max | 8.50-9.50 | 0.30-0.60 | 0.4 | 0.15-0.25 | N 0.03-0.07 |
| Al 0.02 max |
| Cb 0.04-0.09 |
| W 1.5-2.00 |
| B 0.001-0.006 |
| Ti 0.01 max |
| Zr 0.01 max |
| ASTM A106 | Grade B | | 0.3 | 0.29–1.06 | 0.035 | 0.035 | 0.1 | 0.4 | 0.15 | 0.4 | 0.08 | |
| Grade C | | 0.35 | 0.29–1.06 | 0.035 | 0.035 | 0.1 | 0.4 | 0.15 | 0.4 | 0.08 | |
6. Mechanical Properties
| Standards | Steel pipes No. | Tensile strength | Yield strength | Elongation | Impact energy | Hardness |
| (Mpa) | (Mpa) | (%) | (J) |
| ASTM A335 | P5 | ≥415 | ≥205 | ≥22 | ≥35 | ≤187HB |
| P9 | ≥415 | ≥205 | ≥22 | ≥35 | |
| P11 | ≥415 | ≥205 | ≥22 | ≥35 | ≤163HB |
| P12 | ≥415 | ≥220 | ≥22 | ≥35 | ≤163HB |
| P22 | ≥415 | ≥205 | ≥22 | ≥35 | ≤163HB |
| P91 | 585～760 | ≥415 | ≥20 | ≥35 | ≤250HB |
| P92 | ≥620 | ≥440 | ≥20 | ≥35 | ≤250HB |
| ASTM A106 | Grade B | ≥415 | ≥240 | ≥22 | ≥35 | / |
| Grade C | ≥485 | ≥275 | ≥20 | ≥35 | / |
7. Available Size Range:
| OD | Thickness |
| mm | inch | mm | SCH |
| 88.9~1422 | 3''~ 56'' | 2.11~140 | ≥SCH10 |
| *If the steel grades and size you are looking for are not listed above, please contact us for further information. |
